Universal Gate Valve Lockout Device with Durable Coated Cable
- Overview
- Detailed Photos
Basic Info.
| Model NO. | M-H13 |
| Type | Valve Lockout |
| Structure | Padlock&Key |
| Material | Engineering ABS |
| Usage | Household, Commercial, Industrial |
| Selling Units | Single Item |
| Product Name | Gate Valve Lockout |
| Jaw Width | 40mm |
| Color | Red |
| Service | Support OEM |
| Lock Range | Can Be Adjusted |
| Suitable for | Industrial Safety |
| Single Gross Weight | 0.250kg |
| Transport Package | in Carton |
| Specification | 18x6x3cm |
| Trademark | QVAND |
| Origin | Zhejiang, China |
| Production Capacity | 30000 PCS Per Month |
Packaging & Delivery
Package Size20.00cm * 20.00cm * 5.00cm Package Gross Weight0.500kgProduct Description
Part No.:M-H13 series
Universal Valve Lockout
a) Made of industrial grade steel and nylon materials.b) Universal type, suitable for different valve handles.c) Applicable to lock the handle with maximum width 4mm thickness 2.8mmd) The default color is RED, other colors can be customized.
01. Lock Body Material, the lock body and button are made of engineering plastic reinforced nylon PA. Which is corrosion-resistant, impact resistant, and temperature resistant(-57~177), suitable for various operating environments. The lock body can be customized with flame-retardant material.
02. With two arms design, the stainless steel round steel support rod is suitable for two stop arms to lock the 3-way or 5-way valve, or lock the valve at the throttle position for operation control, which can effectively manage and prevent accidental start.
03. Serrated edge, with stainless steel serrated design, it enables the lock to be firmly fixed on the butterfly valve handle, not easy to loosen, and effective equipment locking us more convenient for safe management.
04. Hand wheel tightening, the lock adopts a hand wheel screw tightening device, so that the lock can be easily fixed on the valve handle without any tools to achieve the purpose of equipment locking.
| Model | Material | Specification |
| M-H13 | Steel and Nylon | Standard clamp width 40mm and height 28mm,for butterfly valves. |
| M-H13-1 | Steel and Nylon | Cable attachable for gate valves. |
| M-H13-2 | Steel and Nylon | Single arm suitable for quarter-turn ball valve. |
| M-H13-3 | Steel and Nylon | Single arm suitable with cable attachable for most special devices. |
| M-H13S | Steel and Nylon | Smallest clamp width 25mm and height 15mm. |
| M-H13L | Steel and Nylon | Biggest clamp width 40mm and height 45mm. |
| M-H13-4 | Steel and Nylon | Double arms suitable for 3 to 5 way valve.For most special devices. |
| M-H13-5 | Steel and Nylon | Double arms with cable ,for most special devices. |
